bushing type Italian frame scaffolding

It’s a popular scaffolding widely used in Italy and others European country.

Connection between the frameworks is carried out by means of pipe horizontal ledgers and diagonal braces featuring - at the ends - forged steel pins, which are inserted into bushings (rings) welded onto the uprights of the frames.

A whole bushing type scaffolding includes frames, horizontals, diagonals, planks, toe boards, ladders, screw jack bases etc.

It’s easy to install, and a good choice for your projects.

Feature:

Pitch: 1800 mm

Frame height: 2000 mm

Frame depth: 1050 mm

Half frame height: 1240 mm

Lenght of horizontal ledgers centre distance: 1725 mm

Length of diagonal braces centre distance: 2100 mm

Frame weight: 18.50 kg

Half frame weight: 14.00 kg

Horizontal ledgers weight: 2.60 kg

Diagonal braces weight: 3.10 kg

Material: Steel

Finished: Powder coating

Delivery time: 30 days

Packing: Steel rack
